SMTCL HTC40Q High Efficiency High Precision Motor Shaft Processing Horizontal CNC Lathe Machine with Bar Feeder

Product advantages:

• High efficiency: Configurable servo tailstock, operates at high speed, without impact clamping, eliminates defective raw materials, and enhances processing efficiency.
• High precision: The entire machine is designed with thermal balance, with a product batch capacity of CMK ≥ 2.0 (IT6 grade).
• Multi-functional and easily expandable: Configurable power tool holder, center rest, and other modules to meet customers' multi-process processing needs.
• Imported guide rails, ball screws, main shaft bearings, and Taiwan-style chuck oil cylinders are used.
• Completely upgraded, with outstanding performance: Enhanced capabilities for reaming, U-drilling, hard turning, large length-to-diameter ratio processing, and fine processing.
• Optional features include power spindles, heavy-duty type, turning centers, vertical/interpolation Y-axis, linear motors, high-precision turning, multi-axis series, and automated production lines, meeting customers' flexible selection requirements for various scenarios.
• Efficient programming, unique interface, easy to use and operate.
• Automated processing line, ensuring the machining accuracy of basic components, with core components independently produced.
• Excellent overall performance of the machine, with manufacturing process refined down to 98 steps and 525 quality inspection points.
• Evaluated by a third-party testing institution, the overall performance level has reached the benchmark equipment standard of Japanese equipment.

Product performance:

1. High Precision:

   Double-fixed pre-stretched screw structure
   High-precision C3 grade ball screw
   Error compensation technology

2. High Efficiency:

   Spindle speed: 4500 rpm
   Two-axis rapid movement: 30 m/min
   High-efficiency servo turret

3. High Performance:

   Small floor area
   Quantitative process standards
   Strict inspection standards

Feature 1: Precision manufacturing, stable & reliable

525 quality inspection items, doubled compared with original standards

New intelligent testing process definesa brand-new standard

Evaluated by third-party testing institutions,overall performance has reached the levelof Japanese benchmark equipment

Feature 2: Fully upgraded, superior performance

Comprehensive improvement in heavy cutting, U-drilling, hard turning, and finishing capabilities

Feature 3: Platform development, full-domain adaptation

Excellent scalability: Electric spindle, heavy-duty type, turning center, vertical inproduction lines, etc., meeting customers' flexible configuration needs in various erpolation Y-axis, linear motor, high-precision turning, multi-axis series, automated scenarios

Feature 4: Accumulated strength, high precision & efficiency

Efficient programming, unique interface

Efficient solutions, over 5000 accumulated schemes

Comprehensive improvement in component precision,process precision, factory precision, and machiningprecision

Product Paramenters:
